PUMPING SOLUTIONS
Elvaro-Press 130-XS PU / 230-XS PU
Compact Digital Pressurisation Units for Sealed Systems
The Elvaro-Press range offers compact, wall-mounted, fully enclosed digital pressurisation units designed for light commercial and residential use. With a user-friendly microprocessor, these units ensure consistent top-up pressurisation in sealed systems, maintaining minimum system pressure effortlessly.
Ideal for heating systems with up to a 200L expansion vessel or chiller systems using up to a 50L expansion vessel, the Elvaro-Press is available in both single or twin pump configurations.
If you have any questions, feel free to call us or use our quote form
To speak to one of our agents online, click here
Key Features
System Volume Capacity: Up to 2,600 litres
Flow Rate: 0.5 l/min
Internal Break Tank: 1.2L internal Cat5 WRAS-approved
Electric Pump: 230V, delivering 50L/h
Colour & Finish: White (RAL 9003) with self-finish galvanised steel
User Interface: Simplified menu with 0.1 bar pressure increments
Alarm Options: Built-in alarm activation and volt-free contact for common alarms (High/Low Pressure)
Fluid Protection: Category 5 Visible AB Weir Overflow
Pump Protection: Includes runtime limiter
Technical Specifications
System Temp at Connection Point: 5°C to 85°C
Ambient Temp Range: 5°C to 40°C
Pressure Rating: PN 6
Humidity: Max 60-70% RH, non-condensing
Noise Level: <75 dBA
Certifications & Standards
PED 2014/68/EU
IEE Electrical Safety Guidance
EMC 2004/108/EC
BS 7074 Parts 1–3
Machinery Directive 2006/42/EC
EN 61000 Series (1-6): Immunity and emission standards for industrial and residential use
CE Marked
IP54 Rated (BS EN60529)
WRAS Approved Float Valve (BS1212)
Construction Materials
Cabinet: CR4 powder-coated or galvanised mild steel
Float: WRAS-approved
Break Tank: Polypropylene
Pipework: Braided flexhose / EPDM / Nylon
Valves: Brass / PTFE
Connection: Brass / Polypropylene
Applications
Light commercial systems
Residential heating or cooling systems
Suitable for sealed heating/chiller systems
